- AquaPath 5,000 litre – heavy duty polyethylene water cartage tank, backed with 25-year warranty
- Engineer approved tank design for maximum safety
- Food grade polyethylene, fully UV stabilised
- Engineer tested Liquid Locker Safety System for safety and stability, eliminates surge
- Heavy duty skid mount frame with forklift pockets
- 6.5HP Honda recoil start petrol engine couple to 1” Twin Impeller Davey Pump 400L/min
- Hose reel with 36m x 19mm hose and twist type nozzle
- Sight level tube
-
Options available: Dual Deflector Spray Bar, Wireless In Cab Remote Controls, Hydrant Filler Lid, Diesel Engine
- Tare weight 720kg
- Weight when full of water 5,720kg
- Overall dimensions: 3663(L) x 2000(W) x 1836(H)
| Weight: | 720kg |
| Length: | 3663mm |
| Width: | 2000mm |
| Height: | 1836mm |
AquaPath™
5000L AquaPath™ Slip On Water Cart / Fire Fighting Unit
PFU5000LZPRICING DISPLAYED IS THE FROM PRICE. COST MAY VARY DUE TO OPTIONAL INCLUSIONS
1800 816 277
Contact our team to find out:
- If this product is right for you
- Info and pricing on options & accessories
- Stock availability & delivery timeframe
- More about our nation-wide subsidised freight
- AquaPath 5,000 litre – heavy duty polyethylene water cartage tank, backed with 25-year warranty
- Engineer approved tank design for maximum safety
- Food grade polyethylene, fully UV stabilised
- Engineer tested Liquid Locker Safety System for safety and stability, eliminates surge
- Heavy duty skid mount frame with forklift pockets
- 6.5HP Honda recoil start petrol engine couple to 1” Twin Impeller Davey Pump 400L/min
- Hose reel with 36m x 19mm hose and twist type nozzle
- Sight level tube
-
Options available: Dual Deflector Spray Bar, Wireless In Cab Remote Controls, Hydrant Filler Lid, Diesel Engine
- Tare weight 720kg
- Weight when full of water 5,720kg
- Overall dimensions: 3663(L) x 2000(W) x 1836(H)
| Weight: | 720kg |
| Length: | 3663mm |
| Width: | 2000mm |
| Height: | 1836mm |
Features
Rubber mounted to reduce vibration, a Genuine Honda GX200 Petrol Engine with Davey Twin Impeller Pump
Australian Made, low profile, UV stabilized poly tank
Complete with 36m x 19mm Hose, Safety Locking Catch and Adjustable Twist Type Fire Fighting Nozzle
Hot dip Galvanised steel frame with Forklift Pockets
Skid Design allows for easy mounting onto any flat truck or trailer
Fill The Tank Through Your Pump Quickly From External Water Source
Prevent Liquid Surge for Safe and Smooth Travelling
With adjustable spray pattern
“We needed a water cart to transfer water to our mud mixing units on site, this [TTi AquaPath] saves a lot of downtime….It’s flexible to use – we use it as a spray cart as well, to hose down our yard.”
Daniel, Healesville Directional Drilling – AquaPath™
“All the previous water carts we used have never had the guts or the power to compete with the wind in the Northern Suburbs, but with the TTi one, we have plenty of pressure to get the watering done.”
Gareth, Regal Innovations – AquaPath™
“So we have 5 or 6 of these units across the company. They’re very versatile, easy to fill up – they just make things a lot easier on site”
Michael, ACE Contractors – AquaPath™
FAQs
What types of liquids can be stored in the AquaPath water cartage unit?
The AquaPath is designed for water transport. It can hold other compatible liquids. Contact us for a liquid compatibility chart.
Can the AquaPath be used in remote locations without access to power?
Yes. It is suitable for use in remote locations without mains power.
What maintenance is required for the pump and engine?
Inspect the pump for debris and confirm smooth operation. Follow the engine service schedule in the owner’s handbook.
How can I ensure the stability of the AquaPath when transporting water?
Secure the unit on a stable and level surface. Load the tank correctly. The LiquidLocker Safety System helps reduce surge.
Is there an accessory for remote operation of the pump?
Yes. A wireless in-cab remote is available. Check the product page for compatibility.
What is the best practice for storing the AquaPath when not in use?
Empty and clean the tank before storage. Store the unit in a sheltered location for long-term protection.
